SF24A-SZ

Temperature Sensor

Voltage AC/DC:
AC/DC 24 V

Power consumption (running):
5 W

Power consumption (holding):
3 W

Power Consumption For Wire Sizing:
7 VA

Connection Supply Control:
Cable 1 m, 4x 0.75 mm²

Torque:
20 Nm

Control type:
DC 0.5...10 V

Direction Of Motion Motor:
Selectable with switch L/R

Direction of rotation (fail-safe):
Selectable by mounting L/R

Manual override:
By means of hand crank and locking switch

Angle of rotation:
95°

Running time (motor):
150 s / 90°

Running time (fail-safe):
<20 s

Mechanical interface:
Universal shaft clamp 10...25.4 mm

Protection category:
IP54

Degree Of Protection NEMA:
NEMA 2

Enclosure Type:
UL Enclosure Type 2

Ambient Temperature:
-30...50°C [-22...122°F]
