LF24-SZ

Temperature Sensor

Voltage AC/DC:
AC/DC 24 V

Power consumption (running):
2.5 W

Power consumption (holding):
1 W

Power Consumption For Wire Sizing:
5 VA

Connection Supply Control:
Cable 1 m, 4x 0.75 mm²

Torque:
4 Nm

Control type:
Modulating

Direction Of Motion Motor:
Selectable with switch L/R

Direction of rotation (fail-safe):
Selectable by mounting L/R

Manual override:
No

Angle of rotation:
95°

Running time (motor):
150 s / 90°

Running time (fail-safe):
<20 s

Mechanical interface:
Universal shaft clamp 8...16 mm

Protection category:
IP54

Ambient Temperature:
-30...50°C [-22...122°F]
